Online checkweigher capable of weighing 1-50kg

Online checkweigher capable of weighing 1-50kg
Online checkweigher capable of weighing 1-50kgOnline checkweigher capable of weighing 1-50kgOnline checkweigher capable of weighing 1-50kgOnline checkweigher capable of weighing 1-50kgOnline checkweigher capable of weighing 1-50kg
group name
Online automatic checkweigher
Min Order
1 piece
brand name
Syndar
model
CW8060L10,CW10060L30,CW12060L50
Delivery clauses under the trade mode
FOB, EXW, Express Delivery
Acceptable payment methods
T/T
update time
Thu, 26 Nov 2020 12:13:07 GMT

Paramtents

  • Automatic checkweigher display division 1g;

  • Check weight range 0.1-10kg;

  • checkweigher accuracy ±8-15g;

  • checkweigher reject system device push rod type and slide type are optional;

  • The number of checkweigher scales 1 standard, 3 optional;

Packging & Delivery

  • Min Order1 piece

Briefing

It can clearly reflect the weight change of the inspected product, and is suitable for the inspection of products below 50KG.

Detailed

Using Mid range online checkweigher, you can:
Checkweigher machine net content detection: single product (travel suitcase, rubber box, rubber parts, case checkweigher, aerosol checkweigher, etc.) weight detection;
The high speed checkweigher system (including HMI) reaches IP69 level and is proven to resist most corrosive cleaners and high-pressure cleaners. The tabletop is designed to be easy to clean.

Mid range online checkweigher advantage
Mid range online checkweigher is SYNDAR's new automatic checkweigher machine. The SYNDAR checkweigher manufacturers are suitable for product measurement under 50kg and are widely used in production lines.

The main interface of checkweigher equipment comprehensively displays the weighing data, production data and parameter settings of the current product.
Check weight line chart, which clearly reflects the current product weight change trend.
Checkweigher definition display mode: gross weight, net weight, difference weight.
Online weight check machine has a built-in multi-language operation interface.
Product number
CW8060L10
CW10060L30
CW12060L50
Display index
1g
1g
1g
Checkweighing range
0.1-10kg
0.2-30kg
0.5-50kg
Checkweighing accuracy
±8-15g
±10-15g
±10-15g
Weighing section size
L 800mm*W 600mm
L:1000mm*W 600mm
L 1200mm*W600mm
Applicable product size
L≤600mm,W≤600mm
L≤800mm,W≤600mm
L≤1000mm,W≤600mm
Weighing control system
Use SYNDAR weighing controller system V1.15
Belt speed
5-80/minute
Quantity
20-50 kinds
Rejection device
Push rod type and slide type are optional.
Number of checkweighing sections
Standard 1 stage, optional 3 stages;
Standard technical parameters
Power supply: standard single-phase AC200~240V, 50/60Hz, 0.4KW, optional three-phase AC380V, 50/60Hz, 0.4KW
Air source: dry 0.5~0.8MPa (5~8bar)
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Humidity: 10~90%RH, no condensation
checkweigher high speed protection level: IP30, IP54, IP65 optional
Noise: ≤75db
Machine weight: ≈60kg
Working height: 700±50mm (confirm when ordering other heights)
Material
checkweigher load cell: aluminum, alloy steel optional
Roller: carbon steel
Structure: stainless steel 304, carbon steel optional
Conveyor belt: black, PVC wear-resistant belt
Product size chart
Features of Glass X-ray inspection:
Online weight check machine touch screen built-in easy-to-understand operating instructions
checkweigher load cell: IO port diagnosis, sensor diagnosis, communication diagnosis and other fault diagnosis, to help customers quickly determine the point of failure.
A complete set of logistics Checkweigher Solutions can be formed to reduce costs and improve efficiency.
Applications
SYNDAR checkweigher manufacturers will select and integrate the most convenient weighing machine for your bakery or snack packaging line with your support.
The industrial checkweigher can detect whether there are abnormalities such as over-packing or under-packing of packaged products, such as electronic product detection
SYNDAR Technology also provides users with hardware parts and hardware automatic Checkweigher Solutions.
SYNDAR checkweigher load cell can monitor the entire packaging process, such as instant noodle production line and rice production line.
